1. The ESC has first-class quality and high reliability.
2. Strong flow resistance.
3. It has multiple protection functions such as input voltage abnormality protection, battery low voltage protection, overheats protection, and throttle signal loss protection.
4. It has three start modes: normal start, soft start, and super soft start, compatible with fixed-wing aircraft and helicopters.
5. Accelerator stroke can be set, and compatible with various remote controllers. It has a smooth and delicate speed control feel and first-class speed control linearity.
6. The maximum speed can reach 210000 RPM (2-pole motor), 70000 RPM (6-pole motor), and 35000 RPM (12-pole motor).

Programmable Items (The option written in bold font is the default setting)
1. Brake Setting： Enabled / Disabled
2. Battery Type： Lipo / NiMH
3. Low Voltage Protection Mode(Cut-Off Mode)： Soft Cut-Off (Gradually reduce the output power) /Cut-Off (Immediately stop the
output power)
4. Low Voltage Protection Threshold(Cut-Off Threshold)：Low / Medium / High
1) For lithium batteries, the battery cell number is calculated automatically. Low/medium / high cutoff voltage for each cell is:
2.85V/3.15V/3.3V. For example: For a 3S Lipo, when the “Medium” cutoff threshold is set, the cut-off voltage will be:
3.15*3=9.45V
2) For NiMH batteries, low / medium / high cutoff voltages are 0%/50%/65% of the startup voltage (i.e. the initial voltage of
the battery pack), and 0% means the low voltage cut-off function is disabled. For example: For a 6 cells NiMH battery, the fully
charged voltage is 1.44*6=8.64V, when the “Medium” cut-off threshold is set, the cut-off voltage will be: 8.64*50%=4.32V。 5. Startup Mode： Normal /Soft /Super-Soft (300ms / 1.5s / 3s)
a) Normal mode is suitable for fixed-wing aircraft. Soft or Super-soft modes are suitable for helicopters. The initial acceleration of
the Soft and Super-Soft modes is slower, it takes 1.5 seconds for Soft startup or 3 seconds for Super-Soft startup from initial
throttle advance to full throttle. If the throttle is completely closed (throttle stick moved to bottom position) and opened again
(throttle stick moved to top position) within 3 seconds after the first startup, the re-startup will be temporarily changed to normal
mode to get rid of the chance of a crash caused by a slow throttle response. This special design is suitable for aerobatic flight
when quick throttle response is needed.
6. Timing： Low / Medium / High,( 3.75°/15°/26.25°)
Usually, low timing is suitable for most motors. To get a higher speed, a High timing value can be chosen.
