We are committed to developing small and refined products， This underwater brushless thruster is very suitable for nest boats, trawlers, unmanned boats, school model teams, and DIY, waterproof grade is ip68 and is applicable to the marine environment.
Lightweight
only 118g for this one.
Small Size
High thrust and efficiency
| Model | volts | Reverses Amps | Reverses watts | Reverses Thrust | Forward Rotation Amps | Forward Rotation Watts | Forward Rotation Thrust |
| 380KV | 12V | 6.4A | 76.8W | 1400g | 6.3A | 75.6W | 1450g |
| 380KV | 14V | 7.8A | 109.2W | 1770g | 7.7A | 107.8W | 1790g |
| 380KV | 16V | 9.4A | 150.4W | 2100g | 9.3A | 148.8W | 2150g |
| 380KV | 18V | 11.0A | 198.0W | 2530g | 10.8A | 194.4W | 2550g |
| 380KV | 20V | 12.7A | 254.0W | 2780g | 12.5A | 250.0W | 2810g |
| 380KV | 22V | 14.4A | 316.8W | 3000g | 14.1A | 310.2W | 3100g |
| 380KV | 24V | 16.0A | 384.0W | 3550g | 15.9A | 381.6W | 3580g |
| 550KV | 12V | 14.0A | 168.0W | 2160g | 13.5A | 162.0W | 2190g |
| 550KV | 14V | 16.5A | 231.0W | 2550g | 16.0A | 224.0W | 2580g |
| 550KV | 16V | 20.5A | 328.0W | 3150g | 20.4A | 326.4W | 3200g |
ESC
The underwater brushless thruster needs to be driven and controlled by an ESC. Since the maximum current during use will exceed 30A, it is recommended to choose a 50A ESC， When the power is high, heat dissipation is required, otherwise, the overheating protection of the ESC may cause the motor to slow down or stop.
Matters Needing Attention
It is forbidden to carry out the sealing test with positive or negative pressure, otherwise, it may cause problems such as water leakage in the line.
Our Goal
Make your interests more efficient, more economical, and longer
